A rutile coated all position stainless steel electrode which contains 19% Cr and 10% Ni with extra low carbon (C:< 0.04%).The extra low carbon prevents intergranular corrosion at elevated temperatures in the range of 4250C - 8500C. The weld metal has excellent resistance to cracking, corrosion and scaling up to 8000C. Welds are of radiographic quality.

Applications

• Welding of AISI grades 302, 304, and 304L and 308L.
• Useful in dairy and chemical industries.



Weld Metal Chemistry (%):

C	Mn	Si	S	P	Ni	Cr
0.04 max	0.50 - 2.50	0.80 max	0.02 max	0.03 max	9.0-11.0	19.0-21.0



All Weld Mechanical Properties:

UTS (N/mm2)	Elongation (%) (L=4xD)	Ferrite No.
530-620	38-46	3-7



Welding Currents: (Amp)

2.5 mm	3.15 mm	4.0 mm	5.0 mm
50-80	80-110	120-150	160-200
