A rutile type all position electrode with good operating characteristics. Operates with equal ease with both AC and DC (-) currents. Deposits sound bead having good appearance. Weld deposit is of radiographic quality.

Applications

• General purpose fabrication.
• Storage tanks fabrication
• Metal structures and equipments.
• Shaft builds up.
• Pipe lines and pressure vessels.
• Railway wagons, carriages and automobile bodies.
• Ships, railway coaches, bridges and boilers.



Weld Metal Chemistry (%):

C	Mn	Si	S	P
0.10 max	0.35 - 0.50	0.30 max	0.03 max	0.03 max



All Weld Mechanical Properties:

C	YS (N/mm2)	Elongation (%) (L=4xD)	CVN Impact values	At temp.
410-540	360-440	22-26	50-80 J	0°C



Welding Currents: (Amp)

2.5 mm	3.15 mm	4.0 mm	5.0 mm
60-80	90-130	140-180	180-230
