WELDING MACHINE MUTIPROCESS 6001V

MUTIPROCESS 6001V - WELDING MACHINE

Product Code: GP8349

Enquiry Now

Description

The Multiprocess 6001V is an extra heavy-duty 500-Amp welding machine, capable of Stick welding, MIG welding, Flux cored welding, Gouging or TIG welding with a lift start. It’s robust design and 100% duty cycle make this an ideal all-around workhorse for all medium to heavy-duty applications.

Features

Specially designed for tough conditions.
Extra heavy duty, Robust design and reliable.
High power at 100% Duty cycle, tested in 104°F/40°C and 140°F/60°C.
Excellent design characteristics ensures welding quality, precise arc striking and highly stable arc.
Fully encapsulated PCB to avoid dust contamination.
Automatic compensation for main power fluctuations within ± 20%.
Electronic continuous control of inductance.
Excellent CC/CV characteristic ensures high quality and trouble-free welding.
Exceptional welding characteristics in MIG/MAG, Flux Cored, Gouging.
Precise arc striking and a highly stable arc.
User friendly parameters settings.
Comprehensive 4-Year Warranty.

Specifications

Multiprocess 6000 Series Technical Specification	Multiprocess 6001V- 575 V
Process	MIG	Stick Electrode	TIG
Input Voltage Range (Three Phase, 50/60 Hz)	575 V (-20%,+10%)
Input Voltage Range (Three Phase, 50/60 Hz)	Parameters In 575 V (-20%,+10% )
Primary Current@Max Welding Current	34 A	34 A	26 A
Maximum Primary Effective Current (I1 eff max)	34 A	34 A	26 A
Welding Current Range	30 – 500 A	20 – 500 A	20 – 500 A
Duty Cycle @ Maximum Welding Current in 104° F (40° C)	100% (500 A)	100% (500 A)	100% (500 A)
Welding Current @ 100% Duty Cycle in 104° F (40° C)	500 A @ 100%	500 A @ 100%	500 A @ 100%
Welding Current @ 60% Duty Cycle in 104° F (40° C)	–	–	–
Open Circuit Voltage : Volt	82 V DC	82V DC (27V VRD)	82V DC (27V VRD)
Output Voltage Range	15.5-39 V	20.8-40 V	10.8-30 V
Weight : lb. (Kg)	147 lb. (66 Kg)
Dimensions Including Handle (D, W, H) : inch (mm)	24.8 x 12.2 x 26 inch (630 x 310 x 665 mm)
Input Voltage Range (Three Phase, 50/60 Hz)* (Three Phase 230 /400/ 440 V as option)
